DHCPServerSummary

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page134

D‐LinkUWSUserManual

DHCPServerSummary

BindingsInformation

UsetheDHCPServerBindingsInformationpagetoviewinformationabouttheIPaddressbindingsintheDHCP

serverdatabase.

ToaccesstheDHCPServerBindingsInformationpage,clickLAN>Monitoring>DHCPServerSummary>

BindingInformationinthenavigationtree.

Figure61:BindingsInformation

•Ifyouchangeanysettings,clickSub

mittoapplythechangestothesystem.

Table51:BindingsInformationFields

Field Description

DHCPBinding Selectthebindingstodisplay:

• AllBindings:Showallbindings.

• SpecificBinding:Showaspecificbinding.Whenyouselectthisoption,the

screenrefreshes,andtheBindingIPAddressfieldappears.

BindingIPAddress SpecifytheIPaddressforwhichyouwanttoviewbindinginformation.This

fieldisonlyava

ilableifyouselectSpecificBindingfromtheDHCPBinding

field.

IPAddress DisplaystheclientIPaddress.

HardwareAddress DisplaystheclientMACaddress.

LeaseTimeLeft ShowstheremainingtimeleftintheleaseinDays,HoursandMinutes

dd:hh:mmformat.

PoolAllocationType Showsthetypeofbinding,whichisdynamicorma

nual.
