MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page493

D‐LinkUWSUserManual

CommandButtons

Thepageincludesthefollowingbutton:

• Refresh—Updatesthepagewiththelatestinformation.

ViewingAssociatedClientNeighborAPStatus

TheWLAN>Monitoring>Client>AssociatedClients>NeighborAPspagefortheassociatedclientstatus

showsinformationaboutaccesspointsthattheclientdetects.Theinformationonthispagecanhelpyou

determinethemanagedAPanassociatedclientmightuseforroaming.Usethemenuabovetheta

bletoselect

theMACaddressoftheclientwiththeinformationtoview.

Figure328:AssociatedClientNeighborAPStatus

Table294describestheinformationavailableontheNeighborAPpagefortheassociatedclientstatus.

AccessControlUp ShowswhichACL,ifany,isappliedtotrafficfromtheclienttotheAP

DiffservPolicyDown ShowswhichDiffServpolicy,ifany,isappliedtotrafficfromtheAPtotheclient.

DiffservPolicyUp ShowswhichDiffServpolicy,ifany,isappliedtotrafficfromtheclienttotheAP.

Table294:AssociatedClientNeighborAPStatus

Field Description

APMACAddress ThebaseEthernetaddressoftheDWS‐4000SeriesswitchmanagedAP.

Location TheconfigureddescriptivelocationforthemanagedAP.

Radio Theradiointerfaceanditsconfiguredmodethatdetecte dthisclientasaneighbor.

Table293:AssociatedClientQoSStatus(Cont.)

Field Description
