D-Link DWS-4026 [138/741] Time range summary

ConfiguringTimeRanges

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page138

D‐LinkUWSUserManual

•UseSubmittoaddanewtimerange.

•UseDeletetoremoveanexistingtimerange.

TimeRangeSummary

Usethispagetoviewsummaryinformationaboutconfiguredtimeranges.

Toaccessthispage,clickLAN>Administration>TimeRange>Summary.

Figure65:TimeRangeSummary

Table55:TimeRangeSummary

Field Description

TimeRangeName Identifiestheuser‐configurednameofthetimerange.

TimeRangeStatus Showswhetherthetimerangeisactiveorinactive.Atimerangeisinactiveif

thecurrentdayandtimedoesnotfallwithinthetimeentryspecifiedinthe

timerange.

PeriodicEntryCount Showsthenumberofperiodicen

triesconfiguredforthetimerange.

AbsoluteEntry Showswhetheranabsoluteentryisconfiguredforthetimerange.
