ConfiguringRIP

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page301

D‐LinkUWSUserManual

•Ifyoumakechangestothepage,clickSubmittoapplythechangestothesystem.

RIPInterfaceConfiguration

UsetheRIPInterfaceConfigurationpagetoenableandconfigureortodisableRIPonaspecificinterface.

Todisplaythepage,clickLAN>L3Features>RIP>InterfaceConfigurationinthenavigationtree.

Figure196:RIPInterfaceConfiguration

AutoSummaryMode SelectEnableorDisablefromthedropdownmenu.Ifyo

uselectEnable,

groupsofadjacentroutesaresummarizedintosingleentries,inorderto

reducethetotalnumberofentries.ThedefaultisDisable.

HostRoutesAcceptMode SelectEnableorDisablefromthedropdownmenu.IfyouselectEnable,the

routeracceptshostroutes.ThedefaultisEnable.

GlobalRouteChang

es DisplaysthenumberofroutechangesmadetotheIPRouteDatabasebyRIP.

Thisdoesnotincludetherefreshofaroute'sage.

GlobalQueries DisplaysthenumberofresponsessenttoRIPqueriesfromothersystems.

DefaultInformationOriginate Whenenabled,RIPoriginatesadefaultroute(0.0.0.0/0.0.0.0)

DefaultMetric Setsadefaultfo

rthemetricofredistributedroutes.Thisfielddisplaysthe

defaultmetricifonehasalreadybeenset,orblankifnotconfiguredearlier.

Validvaluesare1to15.

Table176:RIPConfigurationFields(Cont.)

Field Description
