ConfiguringRIP

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page302

D‐LinkUWSUserManual

Table177:RIPInterfaceConfigurationFields

Field Description

Slot/Port Selecttheinterfaceforwhichdataistobeconfiguredfromthemenu.

SendVersion RIPVersionthatroutersendswithitsroutingupdat es.ThedefaultisRIP‐2.

Possiblevaluesare:

• RIP‐1:sendRIPversion1formattedpacketsviabroadcast.

• RIP‐1c:RIPversion1compatibilitymode.SendRIPv

ersion2formatted

packetsviabroadcast.

• RIP‐2:sendRIPversion2packetsusingmulticast.

• None:noRIPcontrolpacketsaresent.

ReceiveVersion RIPVersionoftheroutingupdatesthattheroutermustaccept.Thedefaultis

Both.Possiblevaluesare:

• RIP‐1:acceptonlyRIPversion1formattedpackets.

• RIP‐2:accep

tonlyRIPversion2formattedpackets.

• Both:acceptpacketsineitherformat.

• None:noRIPcontrolpacketsisaccepted.

RIPAdminMode SelectEnableorDisablefromthedropdownmenu.BeforeyouenableRIP

version1orversion1conaninterface,youmustfirstenablenetworkdirected

broadcastmo

deonthecorrespondinginterface.ThedefaultvalueisDisable.

AuthenticationType Y oumayselectanauthenticationtypeotherthanNonebyclickingtheModify

button.Youthenseeanewscreen,whereyoucanselecttheauthentication

typefromthedropdownmenu.Possiblevaluesare:

• None:Thisistheinitialin

terfacestate.Ifyouselectthisoptionfromthe

dropdownmenuonthesecondscreenyouarereturnedtothefirstscreen

withoutanyauthenticationprotocolsbeingrun.

• Simple:IfyouselectSimpleyouarepromptedtoenteranauthentication

key .Thiskeyisincluded,inthecleartext,intheRIPhe

aderofallpackets

sentonthenetwork.Allroutersonthenetworkmustbeconfiguredwith

thesamekey.

• Encrypt:IfyouselectEncryptyouarepromptedtoenterbothan

authenticationkeyandanauthenticationID.EncryptionusestheMD5

Message‐Digestalgorithm.Allroutersonthenetw

orkmustbeconfigured

withthesamekeyandID.

IPAddress DisplaystheIPAddressoftherouterinterface.

LinkState SpecifieswhethertheRIPinterfaceisupordown.

BadPacketsReceived DisplaysthenumberofRIPpacketsthatwerefoundtobeinvalidorcorrupt.

BadRoutesReceived Displaysthenumberofro

utes,invalidRIPpackets,whichwereignoredforany

reason,e.g.,thenumberoftriggeredRIPupdatesactuallysentonthis

interface.ThisexplicitlydoesNOTincludefullupdatessentcontainingnew

information.

UpdatesSent Displaysthenumberofrouteupdate s sent.
