ManagingVLANs

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page192

D‐LinkUWSUserManual

DoubleVLANTunnelingSummary

TheDoubleVLANTunnelingSummarypageshowsthedoubleVLANtunnelingconfigurationstatusforallports

onthesystem.

ToaccesstheDoubleVLANTunnelingSummarypage,clickLAN>Monitoring>VLANSummary>DoubleVLAN

Statusinthenavigationtree.

Figure108:DoubleVLANTunnelingSummary

•ClickRefreshtodisplaythemos

tcurrentinformationfromtherouter.

Table92:DoubleVLANTunnelingSummaryFields

Field Description

Interface Selectthephysicalinterfaceforwhichyouwanttodisplayorconfiguredata.

InterfaceMode ThisspecifiestheadministrativemodeforDoubleVLANTagging:

• Enable:DoubleVLANTaggingisenabledforthespecifiedport(orAll

ports).

• Disable:DoubleVLANTaggingisdisabledforthespecifiedport(orAll

ports),whichisthedef

aultvalue.

EtherType Thetwo‐bytehexEtherT ypetobeusedasthefirst16bitsoftheDoubleVLAN

tag:

• 802.1QTag:Commonlyusedtagrepresenting0x8100

• vMANTag:Commonlyusedtagrepresenting0x88A8

• CustomTag:Indicatesthatacustomtaghasbeenconfiguredanddisplays

itsvalue.
