VLANRoutingSummary

UsetheVLANRoutingSummarypagetodisplayinformationabouttheVLANRoutinginterfacesconfiguredon

thesystem.

Todisplaythepage,clickLAN>Monitoring>L3Status>VLANRoutingSummaryinthenavigationtree.

Figure210:VLANRoutingSummary

Table189:VLANRoutingSummaryFields

Field Description

VLANID TheIDoftheVLANwhosedataisdisplayedinthecurrenttablerow .

Slot/Port ThelogicalslotandportnumberassignedtotheVLANRoutingInterface.

MACAddress TheMACAddressassignedtotheVLANRoutingInterface.

IPAddress TheconfiguredIPAddressoftheVLANRoutingInterface.NotethatifaVL

AN

iscreatedandtheIPaddressisnotconfigured,thepagebydefaultshowsan

IPaddressof0.0.0.0.ToconfiguretheIPaddress,gotoLAN>L3Features>IP

>InterfaceConfiguration.

SubnetMask TheconfiguredSubnetMaskoftheVLANRoutingInterface.Thisis0.0.0.0

whentheVLANR

outingInterfaceisfirstconfiguredandmustbeenteredon

theIPInterfaceConfigurationpage.
