ConfiguringIPAccessControlLists

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page352

D‐LinkUWSUserManual

IPACLConfiguration

UsetheIPACLConfigurationpagetoaddorremoveIP‐basedACLs.OnthismenutheinterfacestowhichanIP

ACLappliesmustbespecified,aswellaswhetheritappliestoinboundoroutboundtraffic.RulesfortheIPACL

arespecified/createdusingthe“IPACLRuleConfiguration”page.

Todispla

ytheIPACLConfigurationpage,clickLAN>AccessControlLists>IPAccessControlLists>

Configurationinthenavigationmenu.

Figure240:IPACLConfiguration

Table211:IPACLConfigurationFields

Field Description

IPACL SelectatypeofACLtocreate,orselectanexistingACLtodeletefromthe

dropdownmenu.YoucancreatethefollowingtypesofIPACLs:

• StandardIPACL:AllowsyoutopermitordenytrafficfromasourceIP

address.

• ExtendedIPACL:Allowsyoutopermitorden

yspecifictypesoflayer3or

layer4trafficfromasourceIPaddresstoadestinationIPaddress.Thistype

ofACLprovidesmoregranularityandfilteringcapabilitiesthanthe

standardIPACL.

• NamedIPACL:AllowsyoutocreateanExtendedIPACLthatisidentified

byanamera

therthananumber.TheseACLshavethesamecapabilitiesas

ExtendedIPACLswithrespecttomatchcriteriaandactionssupported.

IPACLID EnteranIDnumberfortheACLtoconfigure.Thisfieldappearsifyouselect

CreateStandardIPACLorCreateExtendedIPACLfr

omtheIPACLdropdown

menu.ForastandardIPACL,theacceptableIDvaluesare1‐99.Foran

extendedIPACL,theacceptableIDvaluesare101‐199.

IPACLName ThisfieldappearsifyouselectCreateNewNamedIPACLfromtheIPACL

dropdownmenu.SpecifyanIPACLNa

mestringwhichincludesonly

alphanumericcharacters.Thenamemuststartwithanalphabeticcharacter.

ThisfieldwilldisplaythenameofthecurrentlyselectedIPACLiftheACLhas

alreadybeencrea ted.
