DefiningSNMPParameters

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page124

D‐LinkUWSUserManual

Ifyoumakeanychangestothepage,clickSubmittoapplythechangestothesystem.Ifyouwanttheswitch

toretainthenewvaluesacrossapowercycle,youmustperformasave.

TrapFlags

UsetheTrapFlagspagetoenableordisabletrapsatacomponentlevelthattheswitchcansendtoanSNMP

manager.Whentheconditionidentifiedbyanactivetrapisencounteredbytheswitch,atrapmessageissent

toanyenabledSNMPTrapReceivers,andamessageisw

rittentothetraplog.Ifthecomponentleveltrapflag

isdisabled,thennotrapissenttotheSNMPManagereveniftheindividualtrapsinthatcomponentare

enabled.

ToaccesstheTrapFlagspage,clickLAN>Administration >SNMPManager>TrapFlagspage.

Table44:TrapRe

ceiverConfigurationFields

Field Description

SNMPTrapName SelectCreate,toconfiguretheSNMPtrapnamefortheSNMPtrappacketto

besenttothetrapmanager.

IfyouhavealreadyconfiguredanSNMPtrapname,youcanselectitfromthe

drop‐downmenutochangethesettingsordeleteit.

SNMPTrapName Whenthepr

eviousfieldissettoCreate,entertheSNMPtrapnameforthe

SNMPtrappackettobesenttothetrapmanager.Thismaybeupto16

character s andiscasesensitive.

SNMPVersion Selectthetrapversiontobeusedbythereceiverfromthepulldownmenu

• SNMPv1.UsesSNMPv1tosendtrapstothereceiver.

• SNMPv2.UsesSNMPv2tosendtrapstothereceiver.

Protocol SelectthetypeofprotocolusedfortheSNMPTrapReceiverConfiguration:

• IPv4.ChooseIPv4toentertheaddressinIPv4format.

• IPv6.ChooseIPv6toen

tertheaddressinIPv6format.

IPAddress/HostName EntertheIPaddressindotted‐decimalformatofthesystemthatreceives

SNMPtrapsfromtheswitch.Alternatively,youcanenterthehostnameofthe

trapreceiver

Status Selectthereceiver'sstatusfromthepulldownmenu:

• Enable:Sendtrapstothereceiver

• Disa

ble:Donotsendtrapstothereceiver.
