ConfiguringAutoVoIP

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page350

D‐LinkUWSUserManual

•Ifyouchangeanyofthesettingsonthepage,clickSubmittosendtheupdatedconfigurationtothe

switch.Configurationchangestakeeffectimmediately.Thesechangeswillnotberetainedacrossapower

cycleunlessaSaveisperformed.

•ClickRefreshtoupdatethepagewiththemostcurrentdatafromtheswit

ch.

AutoVoIPSummary

TodisplaytheAutoVoIPSummarypage,clickLAN>Monitoring>AutoVoIPSummaryinthenavigationmenu.

Figure239:AutoVoIPSummary

Forinformationaboutthefieldsthepagedisplays,seeTable210.

Table210:AutoVoIPConfigurationFields

Field Description

Interface SpecifiesallAutoVoIPconfigurableinterfaces.TheAlloptionrepresentsthe

mostrecentconfigurationsettingsdoneforallports.Thesesettingsmaybe

overriddenonaper‐interfacebasis.

AutoVoIPMode UsetoeitherEnableorDisabletheAutoVoIPmode.ThedefaultisDisable.

TrafficClass Displaysthetrafficclassuse

dforVoIPtraffic.Thedefaultvalueis7.
