•ClickRefreshtoupdatethepagewiththemostcurrentinformation.

•ClickCleartocleartheLLDPstatisticsofalltheinterfaces.

LocalDeviceInformation

UsetheLLDPLocalDeviceInformationpagetoviewthedatathateachportadvertisesthroughLLDP.

TodisplaytheLLDPLocalDeviceInformationpage,clickLAN>Monitoring>LLDPStatus>LocalDevice

Informationinthenavigationtree.

Figure163:LLDPLocalDeviceInformation

Errors DisplaysthenumberofinvalidLLDPfr

amesreceivedbytheLLDPagentonthe

correspondingport,whiletheLLDPagentisenabled.

Ageouts Displaysthenumberofage‐outsthatoccurredonagivenport.Anage‐outisthenumber

oftimesthecompletesetofinformationadvertisedbyaparticularMACServiceAccess

Point(MSAP)hasbee

ndeletedfromtablesassociatedwithremoteentriesbecausethe

informationtimelinessintervalhadexpired.

TLVDiscards DisplaysthenumberofLLDPTLVs(Type,Length,Valuesets)discardedforanyreasonby

theLLDPagentonthecorrespondingport.

TLVUnknowns DisplaysthenumberofLLDPTLVsreceivedonthelocalportswhichwe

renotrecognized

bytheLLDPagentonthecorrespondingport.

TLVMED DisplaysthetotalnumberofLLDP‐MEDTLVsreceivedonthelocalports.

TLV802.1 DisplaysthetotalnumberofLLDPTLVsreceivedonthelocalportswhichareoftype

802.1.

TLV802.3 DisplaysthetotalnumberofLLDPTL

Vsreceivedonthelocalportswhichareoftype

802.3.
