WDS‐ManagedAPInformation

TheWirelessDistributionSystem(WDS)‐ManagedAPfeatureallowsyoutoaddmanagedAPstothecluster

usingover‐the‐airWDSlinksthroughothermanagedAPs.WithWDS,APsmaybelocatedoutdoor swhere

wiredconnectiontothedatanetworkisunavailable,orinremotebuildingsthatarenotconnectedtothema

in

campuswithawirednetwork.

TheWDSAPgroupconsistsofthefollowingmanagedAPs:

•RootAP—Actsasabridgeorrepeateronthewirelessmediumandcommunicateswiththeswitchviathe

wiredlink

• SatelliteAP—CommunicateswiththeswitchviaaWDSlinktothero

otAP

TheWDSlinksaresecuredusingWPA2PersonalauthenticationandAESencryption.

FormoreinformationabouttheWDSfeature,see“ConfiguringtheWirelessDistributionSystem”onpage626

WDSGroupStatusSummary

TheWDSGroupStatusSummarypagedisplayssummaryinformationaboutconfiguredWDSlinks.Atleastone

groupmustbeconfiguredforthefieldstodisplay.ToconfigureaWDSAPgroup,usethepagesavailablewithin

theWLAN>WDSfolder.

Figure352:WDSGroupStatusSummary

ThefollowingtabledescribesthefieldsontheWDSGr

oupStatusSummarypage.

Table318:WDSGroupStatusSummary

Field Description

GroupID UniquenumberthatidentifiestheWDSAPgroup

ConfiguredAPCount NumberofAPsconfiguredinthisWDSAPgroup

ConnectedRootAP

Count

NumberofrootAPscurrentlybeingmanagedbytheswitchtha taremembersofthis

WDSAPgroup.

ConnectedSatelliteAP

Count

NumberofsatelliteAPscurrentlybeingma

nagedbytheswitchthataremembersof

thisWDSAPgroup.
