SNMPTrapConfiguration

UsetheSNMPTrapConfigurationpagetoconfigurewhetherornotSNMPtrapsaresentfromtheCaptive

Portalandtospecifycaptiveportaleventsthatwillgenerateatrap.

AllCPSNMPtrapsaredisabledbydefault.

ToconfigureSNMPtrapsettingsforvariouscaptiveportalfeatures,clickSecurity>CaptivePort

al>SNMPTrap

Configuration.

Figure281:SNMPTrapConfiguration

ThetrapsspecifiedinthetablebelowaregeneratedonlybytheClusterControllerunlessotherwisespecified.

ThefollowingtabledescribestheeventsthatgenerateSNMPtrapswhenthestatusisEnabled.

Note:YoucanconfiguretheCaptivePortaltrapsonlyiftheCaptivePortalTrapModeisenabled,which

youconfigureontheLAN>Administration>SNMPManager>TrapFlagspage.

Table240:SNMPTrapConfiguration

Field Description

CaptivePortalTrapMode Displaysthecaptiveportaltrapmodestatus.Toenableordisablethemode,

useCaptivePortalmenuontheLAN>Administration>SNMPManager>

TrapFlagspage.

ClientAuthenticationFailure

Traps

Ifyouenablethisfield,theSNMPagentsendsatrapwhenaclientattempts

toauthen

ticatewithacaptiveportalbutisunsuccessful.

ClientConnectionTraps Ifyouenablethisfield,theSNMPagentsendsatrapwhenaclient

authenticateswithandconnectstoacaptiveportal.

ClientDatabaseFullTraps Ifyouenablethisfield,theSNMPagentsendsatrapeachtimeanentry

annotbeaddedtotheclientdatabasebecauseitisfull.

ClientDisconnectionTraps Ifyouenablethisfield,theSNMPagentsendsatrapwhenaclient

disconnectsfromacaptiveportal.
