InterfaceAssociation

FromtheInterfaceAssociationpage,youcanassociateaconfiguredcaptiveportalwithaspecificphysical

interfaceorwirelessnetwork(SSID).TheCPfeatureonlyrunsonthewiredorwirelessinterfacesthatyou

specify.ACPcanhavemultipleinterfacesassociatedwithit,butaninterfacecanbeassociatedtoonlyoneCP

atatime

.

ToassociateinterfaceswithCPs,clickSecurity>CaptivePortal>InterfaceAssociation.

Figure271:InterfaceAssociation

Table230describesthefieldsontheInterfaceAssociationpage.

Note:Whenassociatingaphysical(wired)interfacewithacaptiveportalconfiguration,notethe

followingrestrictions:

•CaptiveportalandSTPshouldnotbeenabledonthesamephysicalinterface.

•Captiveportaland802.1Xcannotbeenabledonthesamephysicalinterface.

•Portsecurityandcaptiveportalcannotbeenabledonthesameph

ysicalinterface.

•IfaphysicalinterfaceismadeaLAGmember,thecaptiveportalbecomesdisabledontheinterface.

Table230:GlobalCaptivePortalConfiguration

Field Description

CPConfiguration Liststhecaptiveportalsconfiguredontheswitchbynumberandname.

Associated

Interfaces

Liststheinterfacesthatarecurrentlyassociatedwiththeselectedcaptiveportal.Wireless

interfacesareidentifiedbythewirelessnetworknumberandSSID.Physical(wired)

interfacesareidentifiedbythePortDescriptionthatincludesslotnumber,portnu

mber,

andinterfacetype.

InterfaceList ListstheinterfacesavailableontheswitchthatarenotcurrentlyassociatedwithaCP.

WirelessinterfacesareidentifiedbythewirelessnetworknumberandSSID.Physical

(wired)interfacesareidentifiedbythePortDescriptionthatincludesslotnumber,port

number,andinterfacetype.
