MultipleImageServi ce

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page173

D‐LinkUWSUserManual

Figure90:MultipleImageService

TheActiveImagepagecontainsthefollowingfields:

•ClickActivatetomaketheimagethatisselectedintheImageNamefieldthenextactiveimagefor

subsequentreboots.

•ClickDeletetoremovetheselectedimagefrompermanentstorageontheswitch.Youcannotdeletethe

activeimage.

•ClickChangetou

pdatetheimagedescriptionontheswitch.

•Ifthefileyouuploadedcontainsthebootloadercodeonly,clickUpdateBootcode.

Table76:MultipleImageServiceFields

Field Description

ImageName SelectImage1orImage2fromthemenutoactivateonthenextreloadortobedeleted.

Current‐active Displaysnameofcurrentactiveimage.

Next‐active Displaysthenameoftheimagethatissettobeactivethenexttimetheswitchreloads.

Image

Description

Ifdesired,enteradescriptivenamefo

rthere spectiveImage1orImage2softwareimages.

Note:Afteractivatinganimage,youmustperformasystemresetoftheswitchinordertorunthe

newcode.
