MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page462

D‐LinkUWSUserManual

CodeDownloadStatus IndicatesthecurrentstatusofacodedownloadrequestforthisAP.Thepossible

valuesincludethefollowing:

•NotStarted:Nodownloadhasbegun.

•Requested:AdownloadisplannedforthisAP,buttheAPisnotinthecurrent

downloadgroup,soithasn’tbeentoldtostartthedo

wnloadyet.

•Code‐Transfer‐In‐Progress:TheAPhasbeentoldtodownloadthecode.

• Failure:TheAPreportedafailingcodedownload.

•Aborted:ThedownloadwasabortedbeforetheAPloadedcodefromtheTFTP

server.

•Waiting‐For‐APs‐To‐Download:AdownloadfinishedonthisAP,anditiswaiting

rotherAPstofinishdownload.ResetcommandisnotsenttotheAPinthis

state.

•NVRAM‐Update‐In‐Progress:Downloadcompletedsuccessfully.Thereset

commandsenttotheAP.

•Timed‐Out:TheAPdidnotreconnecttotheDWS‐4000Seriesswitchinthefixed

timeinterval.

ConfigurationStatus IndicateswhethertheAPisc

onfiguredsuccessfullywiththeassignedprofile.The

statusisoneofthefollowing:

•NotConfigured:TheprofilehasnotbeensenttotheAPyet,theAPmaybe

discoveredbutnotyetauthenticated.

•InProgress:TheswitchiscurrentlysendingtheAPprofile configurationpacketto

theAP

•Success:TheentireprofilehasbeensenttotheAPandtherewereno

configurationerrors.

•PartialSuccess:TheentireprofilehasbeensenttotheAPandtherewere

configurationerrors,buttheAPisoperational.

• Failure:TheprofilehasbeensenttotheAPandtherewereconfigurationerrors,

theAPisnotoper

ational.

ConfigurationFailure

ErrorMessage

Thisfieldappearsiftheconfigurationstatusindicatesapartialorcompletefailure.

Thefieldprovidesinformationaboutthelastelementthatfailedduring

configuration.ThefieldshowsanASCIIstringfilledinbytheAPcontainingtheerror

messageforthelastf

ailingconfigurationelement.I

ConfigurationFailure

Element

Thisfieldappearsiftheconfigurationstatusindicatesapartialsuccessorfailure.It

showstheelementIDofthelastfailingconfigurationelement.

VendorID VendoroftheAPsoftware,thisislearnedfromtheAPduringdiscovery.

PartNumber HardwarepartnumberfortheAP

,whichislearnedfromtheAPduringdiscovery.

HardwareType HardwareplatformfortheAP,whichislearnedfromtheAPduringdiscovery.

ManagingSwitch IndicateswhethertheAPismanagedbythelocalswitchorapeerswitch.

SwitchMACAddress IdentifiestheMACaddressoftheswitchthatismanagingtheAP

SwitchIPAddress IdentifiestheIPaddressoftheswitchthatismanagingtheAP.

Profile TheAPprofileconfigurationcurrentlyappliedtothemanagedAP,theprofileis

assignedtotheAPinthevalidAPdatabase.

Note:OnceanAPisdiscoveredandmanagedbytheDWS‐4000Se

riesswitch,ifthe

profileischangedinthevalidAPdatabase(eitherlocallyorontheRADIUSserver)the

APmustberesettoconfigurewiththenewprofile.

Table269:DetailedManagedAccessPointStatus(Cont.)
