CreatingPortChannels(Trunking)

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page207

D‐LinkUWSUserManual

AdminMode Selectenableordisablefromthepulldownmenu.WhenthePortChannelis

disablednotrafficwillflowandLACPDUswillbedropped,butthelinksthat

formthePortChannelwillnotbereleased.Thefactorydefaultisenable.

LinkState IndicateswhetherthelinkisUporDown.

STPMode Show

swhethertheSpanningTreeProtocol(STP)AdministrativeModeis

enabledordisabledontheportchannel

StaticMode Showswhetherstaticmodeisenabledforthisportchannel.

LinkTrap Showswhethertosendtrapswhenlinkstatuschanges.IfthestatusisEnabled,

trapsaresent.

ConfiguredPorts Liststheportstha

taremembersofthePortChannel,inSlot/Portnotation.

Therecanbeamaximumof8portsassignedtoaPortChannel.

ActivePorts Liststheportsthatar eactivelyparticipatingmembersofthisPortChannel,in

Slot/Portnotation.

LoadBalance Showsthehashingalgorithmusedtodistributethetrafficloadamong

ava

ilablephysicalportsintheLAG.Therangeofpossiblevaluesmayvarywith

thetypeofswitch.Thepossiblevaluesare:

•SourceMAC,VLAN,EtherType,andsourceport

•DestinationMAC,VLAN,EtherT ypeandsourceport

• Source/DestinationMAC,VLAN,EtherT ype,andsourceport

•SourceIPandSourceTCP/UDPPort

•DestinationIPandDestinationTC

P /UDPPort

• Source/DestinationIPandsource/destinationTCP/UDPPort

Table101:PortChannelStatusFields(Cont.)

Field Description
