ManagingLLDP

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page269

D‐LinkUWSUserManual

•ClickRefreshtoupdatethepagewiththelatestinformationfromtherouter.

NetworkPolicyInformation SpecifiesifnetworkpolicyTLVisreceivedintheLLDPframesonthisport:

• MediaApplicationType:Specifiestheapplicationtype.Typesof

applicationtypesareunknown,voicesignaling,guestvoice,

guestvoicesignalling,softphonevoice,videoconferencing,

streammingvideo,vidoesignalling.Eachapplicationtypetha

tisreceived

hastheVLANID,priority,DSCP,taggedbitstatusandunknownbitstatus.

Aportmayreceiveoneormanysuchapplicationtypes.Ifanetworkpolicy

TLVhasbeenreceivedonthisport,onlythenwouldthisinformationbe

displayed.

• VlanID:SpecifiestheVLANIDa

ssociatedwithaparticularpolicytype.

• Priority:Specifiesthepriorityassociatedwithaparticularpolicytype.

• DSCP:SpecifiestheDSCPassociatedwithaparticularpolicytype.

• UnknownBitStatus:Specifiestheunknownbitassociatedwitha

particularpolicytype.

• TaggedBitStatus:Specifiesthetaggedbitassociatedwithapa

rticular

policytype.

Inventory SpecifiestheinventoryTLVisreceivedinLLDPframesonthisport:

• HardwareRevisions.Specifieshardwareversionoftheremotedevice.

• FirmwareRevisions.Specifiesfirmwareversionoftheremotedevice.

•SoftwareRevisions.Specifiessoftwareversionoftheremotedevice.

• SerialNumber.Specifiesserialnumberoftheremotedevice.

•

ManufacturerName.Specifiesmanufacturer’snameoftheremotedevice.

•ModelName.Specifiesmodelnameoftheremotedevice.

•AssetID.SpecifiesassetIDoftheremotedevice.

LocationInformation SpecifiesiflocationTLVisreceivedinLLDPframesonthisport.

• SubType:Specifiestypeoflocationinformation.

• LocationInformation:Specifiesth

elocationinformationasastringfor

giventypeoflocationID.

ExtendedPoE SpecifiesifremotedeviceisaPoEdevice.

• DeviceType.Specifiestheremotedevice’sPoEdevicetypeconnectedto

thisport.

ExtendedPoEPSE SpecifiesifextendedPSETLVisreceivedinLLDPframeonthisport:

• Available:Specifie

stheremoteport’spowersourcingequipment's(PSE)

powervalueintenthsofwatts.

• Source:Specifiestheremoteport’sPSEpowersource.

• Priority:Specifiestheremoteport’sPSEpowerpriority.

ExtendedPoEPD SpecifiesifextendedPDTLVisreceivedinLLDPframeonthisport.

• Required:Specifiestheremoteport

’spowerdevicepowerrequirement.

• Source:Specifiestheremoteport’sPDpowersource.

• Priority:Specifiestheremoteport’sPDpowerpriority.

Table152:LLDP‐MEDRemoteDeviceInformationFields(Cont.)

Field Description
