IPAddress

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page72

D‐LinkUWSUserManual

Table9:NetworkConnectivityFields

Field Description

Protocol SelectstheIPprotocolversionyouwanttoconfigureontheinterface.

Dependingonyourselection,differentfieldsdisplay.Bothprotocolscanbe

configured.

IPv4Fields:ThesedisplaywhenIPv4isselectedastheprotocol.

IPAddress TheIPaddressofthenetworkinterface.Thefactorydefaultvalueis0.0.0.0

Note:EachpartoftheIPaddressmuststartwithanumberotherthanzero.

Forexample,IPaddresses001.100.192.6and192.001.10.3arenotvalid.

SubnetMask TheIPsubnetma

skfortheinterface.Thefactorydefaultvalueis0.0.0.0.

DefaultGateway ThedefaultgatewayfortheIPinterface.Thefactorydefaultvalueis0.0.0.0.

Burned‐inMACAddress Thisread‐onlyfielddisplaystheMACaddressthatisburned‐intothenetwork

cardatthefactory.ThisMA

Caddressisusedforin‐bandconnectivityifyou

choosenottoconfigurealocallyadministeredaddress.

LocallyAdministeredMAC

Address

YoucanoptionallyconfigurealocallyadministeredMACaddressforin‐band

connectivityinsteadofusingtheburned‐inuniversallyadministeredMAC

address.Inadditiontoenteringanaddressinthisfield,yo

umustalsosetthe

MACaddresstypetolocallyadministered.Entertheaddressastwelve

hexadecimaldigits(6bytes)withacolonbetweeneachbyte.Bit1ofbyte0

mustbesettoa1andbit0toa0;i.e.,byte0musthaveav

aluebetweenx'40'

andx'7F'.

MACAddressType SelecttheMACaddresstouseforin‐bandconnectivity.Thefactorydefaultis

tousetheburned‐inMACaddress.

• Burned‐In:UsethefactorydefaultMACaddress.

• LocallyAdministered:UsetheMACaddressyouenteredintheLocally

AdministeredMACAddressfi

eld.

NetworkConfiguration

ProtocolCurrent

Specifywhattheswitchshoulddofollowingpower‐up.Thefactorydefaultis

None.Theoptionsareasfollows:

• BootP:TransmitaBootprequest

• DHCP:TransmitaDHCPrequest

• None:Donotsendanyrequestsfollowingpower‐up.

ManagementVLANID SpecifiesthemanagementVLANIDoftheswit

ch.Therangeis1‐3965.The

managementVLANisusedformanagementoftheswitch.Thisfieldis

configurableforadministrativeusersandread‐onlyforotherusers.

WebMode ControlswhethertheswitchuserinterfacecanbeaccessedfromaWeb

browser.Thefactorydefaultisenabled.

• Enable:PermitsWe

b‐basedmanagementoftheswitch.

• Disable:ProhibitsWeb‐basedmanagementoftheswitch.IftheWebmode

isdisabled,youmustmanagetheswitchbyusingSNMPortheCLI.

JavaMode ControlswhethertodisplaytheJavaappletthatdisplaysapictureofthe

switchatthetoprigh

tofthescreen.Thefactorydefaultisenabled:

• Enable:Permitstheapplettodisplay.TheJavaappletletsclickonthe

pictureoftheswitchtoselectconfigurationscreensinsteadofusingthe

navigationtreeattheleftsideofthescreen.

• Disable:DoesnotallowtheJavaapplettodisp

lay.Theappletisreplaced

byablankarea.
