ManagingVLANs

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page186

D‐LinkUWSUserManual

Tocreateandconfigureaprotocolgroup,enteragroupID andclickSubmit.Thepagerefreshesandadditional

fieldsappear.

Figure101:ProtocolGroup

•Tocreateormodifyaprotocol‐basedVLANgroup,editthefields,andthenclickSubmit.

•Todeleteanexistingprotocol‐basedVLANgroup,selectthegr

oupfromtheGroupIDfield,andthenclick

DeleteGroup.

Table85:ProtocolGroupFields

Field Description

GroupID Usethedrop‐downmenutocreateanewgrouportoconfiguretheselectedprotocol

group.Youcancreateupto128groups.

GroupID Identifiesthegrouptoconfigure.

GroupName OptionallyenteranametoassociatewithprotocolgroupID.Youcanmodifythenameof

anexistinggr

oup.Youcanenterupto16characters.

VLAN SpecifytheVLANIDtoassociatewiththisgroup.Therangeis1‐3965.

Protocol‐list Specifyoneormoreprotocolstoassociatewiththisgroup.Theprotocollistcanbeany

validcomma(,)separatedstringwith standardarp,ip,ipxkeywords,hexadecimalor

cimalvaluesintherangeof0x0600(1536)to0xFFFF(65535).

Interfaces Selectstheinterface(s)toaddorremovefromthisgroup.CTRL+clicktoselectmultiple

ports.
