PortAccessControl

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page423

D‐LinkUWSUserManual

MaximumRequests Displaystheconfiguredmaximumrequestsfortheselectedport.The

maximumrequestsvalueisthemaximumnumberoftimestheauthenticator

statemachineonthisportwillretransmitanEAPOLEAPRequest/Identity

befor etimingoutthesupplicant.Themaximumrequestsvalueisintherange

of1and10.

VLANAssigned Displa

ystheVLANIDassignedtotheselectedinterfacebytheAuthenticator.

Note:Thisfieldisdisplayedonlywhentheportcontrolmodeoftheselected

interfaceisnotMAC‐based.

VLANAssignedReason DisplaysthereasonfortheVLANIDassignedbytheauthenticatortothe

selectedinterface.Possiblevaluesar

• Radius

•Unauth

•Default

•NotAssigned

Note:Thisfieldisdisplayedonlywhentheportcontrolmodeoftheselected

interfaceisnotMAC‐based.

ReauthenticationPeriod Displaystheconfiguredreauthenticationperiodfortheselectedport.The

reauthenticationperiodisthevalue,inseconds,ofthetimerusedbythe

authenticatorstatemachineonthisporttode

terminewhenreauthentication

ofthesupplicanttakesplace.Thereauthenticationperiodisavalueinthe

rangeof1and65535.

ReauthenticationEnabled Displaysifreauthenticationisenabledontheselectedport.Thisisa

configurablefield.Thepossiblevaluesare'true'and'false'.Ifthevalueis'true'

eauthenticationwilloccur.Otherwise,reauthenticationwillnotbeallowed.

KeyTransmissionEnabled Thisfielddisplaysifkeytransmissionisenabledontheselectedport.Thisis

notaconfigurablefield.Thepossiblevaluesare'true'and'false'.Ifthevalue

is'false',keytransmissionwillnotoccur.Otherwise,keytransmissionis

supportedontheselect

edport.

ControlDirection Thisdisplaysthecontroldirectionforthespecifiedport.Thecontroldirection

dictatesthedegreetowhichprotocolexchangestak eplacebetween

SupplicantandAuthenticator.Thisaffectswhethertheunauthorized

controlledportexertscontrolovercommunicationinbothdirections

(disablingbothincomingandoutgoingframes)orjus

tintheincoming

direction(disablingonlythereceptionofincomingframes).

Note:Thisfieldisnotconfigurableonsomeplatforms.

MaximumUsers Displaysthemaximumnumberofclientsthatcangetauthenticatedonthe

portintheMAC‐baseddot1xauthenticationmode.Thisfieldisconfigurable.

Themaximumusersvalueisinra

ngeof1to16.

UnauthenticatedVLANID DisplaystheUnauthenticatedVLANIDfortheselectedport.Thevalidrangeis

0to3965.

SessionTimeout DisplaystheSessionTimeoutsetbytheRADIUSServerfortheselectedport.

Note:Thisfieldisdisplayedonlywhentheportcontrolmodeofthesele

cted

portisnotMAC‐based.

Table250:PortAccessControlStatusFields(Cont.)

Field Description
