LocatingWLANDevices

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page649

D‐LinkUWSUserManual

ThefollowingtableshowsthefieldsavailableontheDetailedClientTriangulationStatuspage.

CommandButtons

Thepageincludesthefollowingbutton:

• Refresh—Updatesthepagewiththelatestinformation.

Table382:DetailedClientTriangulationStatus

Field Description

MACAddressSelector ThemenucontainstheMACaddressofeachwirelessclientlistedon

thesummarypage.

LocationData Indicateswhetherlocationdataisavailablefortheclient.

DeviceType IndicateswhetherthedeviceisaAssociatedClientoraDetected

Client.Ifthetypeofdevicechanges,thechangemightnotberef

lected

untilthedevicelocationisnextcomputed.

LocationComputationStatus Thestatusofthelastiterationofthelocationcomputationalgorithm:

•NotExecuted

•Success

•Failure

LastSuccessfulComputation Amountoftimeindays,hours,minutes,andsecondsthathaspassed

sincethetriangulationinformationwaslastcomputedsuccessfully.

BuildingNumber Numberthatidentifiesth

ebuildingwherethedeviceisdetected.A

valueof0indicatesthatnodataisavailable.

FloorNumber Numberthatidentifiesthefloorwherethedeviceisdetected.Avalue

of0indicatesthatnodataisavailable.

DetectedXCoordinate IdentifiestheXaxisoffsetsoftheclientfromsomearbitrary0,0poi

nt

onthebuildingfloor.Avalueof0indicatesthatnodataisavailable.

DetectedYCoordinate IdentifiestheYaxisoffsetsoftheclientfromsomearbitrary0,0point

onthebuildingfloor.Avalueof0indicatesthatnodataisavailable.
