ConfiguringGARP

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page200

D‐LinkUWSUserManual

TheGARPStatuspagecontainsthefollowingfields:

Table97:GARPStatusFields

Field Description

SwitchGVRP ShowswhethertheswitchGVRPprotocolisenabledordisabled.

SwitchGMRP ShowswhethertheswitchGMRPprotocolisenabledordisabled.

Slot/Port Identifiesthesysteminterface.

PortGVRPMode ShowstheGARPVLANRegistrationProtocoladministrativemodefortheport.

IfthemodeisDisabled,theprotocolwillnotbeactiveandtheJo

inTime,Leave

TimeandLeaveAllTimewillhavenoeffect.

PortGMRPMode ShowstheGARPMulticastRegistrationProtocoladministrativemodeforthe

port.IfthemodeisDisabled,theprotocolwillnotbeactive,andJoinTime,

LeaveTimeandLeaveAllTimehavenoeff ect.

JoinTimer(

centisecs) ShowsthetimebetweenthetransmissionofGARPPDUsregistering(orre‐

registering)membershipforaVLANormulticastgroupincentiseconds.

LeaveTimer(centisecs) Displaystimelapse,incentiseconds,thattheswitchwaitsbef oreleavingits

GARPstate.LeavetimeisactivatedbyaLeaveAllTimemessagesen

t/received,

andcancelledbytheJoinmessagereceived.Thisallowstimeforanotherstation

toassertregistrationforthesameattributeinordertomaintainuninterrupted

service.

LeaveAllTimer(centisecs) Displaystimelapse,incentiseconds,thatallswitcheswaitbeforeleavingthe

GARPstate.Theleavealltimemustbegreatertha

ntheleavetime. TheLeave

AllTimecontrolshowfrequentlyLeaveAllPDUsaregenerated.ALeaveAllPDU

indicatesthatallregistrationswillshortlybederegistered.Participantswillneed

torejoininordertomaintainregistration.
