Toadda relayentry,clickAdd.ThepagerefreshesandprovidestheconfigurablefieldstoaddaUDPdestination

portandserverIPaddress.

Figure181:AddingaGlobalIPHelperEntry

•ClickSubmittosendtheupdatedconfigurationtotheswitch.Thesechangeswillnotberetainedacrossa

powercy

cleunlessaSaveconfigurationisperformed.

•ClickCancel tocanceltheconfigurationonthescreenandresetthedataonthescreentothelatestvalue

oftheswitch.

ServerAddress ShowstheServerAddresstowhichthepacketswiththegivenUDP

DestinationPortwillberelayed.

HitCount Showsthenumbe

roftimesapackethasbeenforwardedordiscarded

accordingtothisentry.

Remove Todeleteaconfiguredhelperentry,selecttheRemovecheckboxforthe

appropriateentryandclickSubmit.

Table162:IPHelperGlobalConfigurationAddFields

Field Description

UDPDestinationPort(0‐

65535)

ThedestinationUDPportID/PortNameofUDPpacketstoberelayed.Select

theprotocolfromthemenu.Ifyouwanttoconfigureotherthanthelisted

protocols,selectOtherfromthemenu.Thenuserwillbepromptedwiththe

UDPDestinationPortfield.SelecttheDef

aultSettoconfigurefortherelay

entryforthedefaultsetofprotocols.

ServerAddress TheServerAddresstowhichthepacketswiththegivenUDPDestinationPort

willberelayed.
