ConfiguringPortSecurity

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page370

D‐LinkUWSUserManual

•Ifyoumakeanychangestothepage,clickSubmittoapplythenewsettingstothesystem.

Table216:PortSecurityInterfaceConfigurationFields

Field Description

Interface SelectthephysicalinterfaceortheLAGonwhichtoconfigureportsecurity

information.

PortSecurity Determineswhetherportsecurityisenabled.ThedefaultmodeisDisable.

• Enable:LockstheportsothatonlypacketswithallowablesourceMAC

addressescanbeforwarded.Allotherpacketsarediscarded.

• Disable:Thepo

rtisnotlocked,sonoportsecurityre strictionsareapplied.

MaximumNumberof

DynamicallyLearnedMAC

AddressesAllowed

SetsthemaximumnumberofdynamicallylearnedMACaddressesonthe

selectedinterface.Oncethelimitisreached,nomoreaddressesarelearned

ontheport.AnypacketswithsourceMACaddressesthatwe

renotalready

learnedarediscarded.Youcaneffectivelydisabledynamiclockingbysetting

thenumberofallowabledynamicentriestozero.

MaximumNumberof

StaticallyLockedMAC

AddressesAllowed

SetsthemaximumnumberofstaticallylockedMACaddressesontheselected

interface.

AddaStaticMACAddress AddsaMACaddresstotheli

stofstaticallylockedMACaddressesforthe

selectedinterface.OnlypacketswithanallowablesourceMACaddresscanbe

forwarded.

VLANID AddsacorrespondingVLANIDfortheMACAddressbeingaddedtothelistof

staticallylockedMACaddressesfortheselectedinterface.

EnableViolationTraps Enablesordisab

lesthesendingofnewviolationtrapsdesignatingwhena

packetwithadisallowedMACaddressisreceivedonalockedport.ValueisNo

bydefault.

Convertdynamicallylearned

addresstostaticlocked

WhenyouclickMove,allthedynamicallylearnedentriesonthisinterfaceare

addedtothestaticMACad

dresslistforthisinterface.Aftermovingthem,you

canviewtheminthePortSecurityStaticpage.
