PortAccessControl

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page421

D‐LinkUWSUserManual

Figure297:PortAccessControlStatus‐MAC‐basedControlMode

Table250:PortAccessControlStatusFields

Field Description

Interface SelectstheUnitandPorttoview.

ProtocolVersion Thisfielddisplaystheprotocolversionassociatedwiththeselectedport.The

onlypossiblevalueis1,correspondingtothefirstversionofthe802.1x

specification.Thisfieldisnotconfigurable.

PAECapabilities Thisfielddisplaystheportaccessentity(PAE)functionalityofth

eselected

port.Possiblevaluesare"Authenticator"or"Supplicant".Thisfieldisnot

configurable.

ControlMode Definestheportauthorizationstate.Thecontrolmodeisonlysetifthelink

statusoftheportislinkup.Thepossiblefieldvaluesare:

• Auto:Automaticallydetectsthemodeoftheinterface.

• ForceAuthorized:Place

stheinterfaceintoanauthorizedstatewithout

beingauthenticated.Theinterfacesendsandreceivesnormaltraffic

withoutclientport‐basedauthentication.

• ForceUnauthorized:Deniestheselectedinterfacesystemaccessby

movingtheinterfaceintounauthorizedstate.Theswitchcannotprovide

authenticationservicestotheclientthroughtheinterface.

• MA

C‐based:Setsthemodeoftheinterfacetoauthenticationonaper

supplicantbasis.
