MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page446

D‐LinkUWSUserManual

CommandButtons

Thepageincludesthefollowingbutton:

• Refresh—Updatesthepagewiththelatestinformation.

TSPECStatistics(VoiceandVideo)

TotalTSPECPackets

Received

ThenumberofTSPECpacketssentfromthewirelessclienttotheAP.Thenumberis

atotalforallAPsmanagedbytheswitch.

TotalTSPECPackets

Transmitted

ThenumberofTS

PECpacketssentfr omtheAPtothewirelessclient.Thenumberis

atotalforallAPsmanagedbytheswitch.

TotalTSPECBytes

Received

ThenumberofTSPECbytessentfromthewirelessclienttotheAP.Thenumberisa

totalforallAPsmanagedbythes

witch.

TotalTSPECBytes

Transmitted

ThenumberofTSPECbytessentfromtheAPtothewirelessclient.Thenumberisa

totalforallAPsmanagedbytheswitch.

TotalTSPECsAccepted ThenumberofTSPECpacketsthatwereacceptedbyallAPsthattheswitchmanages.

TotalTSPECsRejected ThenumberofTS

PECpacketsthatwererejectedbyallAPsthattheswitchmanages.

TotalRoamingTSPECs

Accepted

ThetotalnumberofTSPECpacketstransmittedbyroamingclientsthatwere

acceptedbyallAPsthattheswitchmanages.

TotalRoamingTSPECs

Rejected

ThetotalnumberofTSPECpacketstransmittedbyroamingclientsthatwer

erejected

byallAPsthattheswitchmanages.

Table258:SwitchStatus/Statistics

Field Description
