BasicSetup

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page544

D‐LinkUWSUserManual

ThefollowingtabledescribesthefieldsontheSSIDpage.

CommandButtons

Thepageincludesthefollowingbuttons:

• Refresh—Updatesthepagewiththelatestinformation.

• Submit—Updatestheswitchwiththevaluesyouenter.Toretainthenewvaluesacrossapowercycle,you

mustperformasaveontheWLANswitch(no

ttheAP).Toperformasave,clickTool>SaveChanges.

• Next—NavigatestothenextpageintheBasicSetupconfiguration.Anychangesyoumadetothecurrent

pagearesavedbeforethenextpageisdisplayed.Toretainthenewvaluesacrossapowercycle,youmust

performasa

veontheWLANswitch(nottheAP).Toperformasave,clickTool>SaveChanges.

Table327:DefaultVAPConfiguration

Field Description

Radio1

Radio2

YouconfiguretheVAPsforRadio1andRadio2separately.Selecttheradioto

configurethesettingsforbeforeyouenabletheVAP.

TheDWL‐3600APisasingle‐radioAP.AnysettingsyouconfigureforRadio1

(802.11a/n)arenotappliedtotheDWL‐3600AP.Ifthesel

ectedHardwareTypeIDfor

theAPprofileisDWL‐3600AP,theradioselectorsarenotavailable.

Network UsetheoptiontotheleftofthenetworktoenableordisablethecorrespondingVAP

ontheselectedradio.

Whenenabled,usethemenutoselectanetworkstoassigntotheVA

P.Youcan

configureupto64separatenetworksontheswitchandapplythemacrossmultiple

radioandVAPinterfaces.Bydefault,16networksarepre‐configuredandappliedin

ordertotheVAPsoneachradio.

EnablingaVAPononeradiodoesnotautomaticallyenableitontheot

herradio.

Note:YoucannotdisablethedefaultVAP,VAP0.

Toconfigureadditionalnetworks,clickWLAN>Administration>Advanced

Configuration>Networks.

Edit ClickEdittomodifysettingsforthecorrespondingnetwork.

WhenyouclickEdit,theWirelessNetworkConfigurationpageappears.

VLAN ShowstheVLANIDoftheVAP.Tochangethisset

ting,clickEdit.

L3Tunnel ShowswhetherL3TunnelingisenabledontheVAP .Tochangethissetting,clickEdit.

Note:WhenL3tunnelingisenabled,theVLANIDisnotused.Infact,theswitchputs

themanagementVLANID,ifany,onthetunneledpackets.

HideSSID ShowswhethertheVA

PbroadcaststheSSID.Ifenabled,theSSIDforthisnetworkis

notincludedinAPbeacons.Tochangethissetting,clickEdit.

Security ShowsthecurrentsecuritysettingsfortheVAP.Tochangethissetting,clickEdit.

Redirect ShowswhetherHTTPredirectisenabled.Thepossiblevaluesforthefi

eldareas

follows:

•HTTP:HTTPRedirectisenabled

•None:HTTPRedirectisdisabled
