BasicSetup

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page550

D‐LinkUWSUserManual

ClientQoSBandwidth

LimitUp

EnterthemaximumallowedclienttransmissionratetotheAPinbitspersecond.The

validrangeis0‐4294967295bps.

Anon‐zeroconfiguredvalueisroundeddowntothenearest64Kbpsvalueforusein

theAP,buttonolessthan64Kbps.Av

alueof0meansthatthebandwidthmaximum

limitisnotenforcedinthisdirection.

ClientQoSAccess

ControlDown

Selectthenameoftheaccesslistappliedtotrafficintheoutbound(down)direction.

OnlyexistingIPaccesslistsarelistedinthemenuandareprefixedwiththeaccesslis

t

type.TocreateanIPaccesslist,usethepagesintheLAN>AccessControlListsfolder.

•OntheIPACLConfigurationpage,createanewstandard,extended,ornamedIP

ACL.

•OntheIPACLRuleConfigurationpage,createoneormorerulestodefinethe

packetmatchcriteriaandtheden

yorpermitactionforeachrule.

Afterswitchingthepackettotheoutboundinterface,theACLrulesarecheckedfora

match.Thepacketistransmittedifitispermitted,anddiscardedifitisdenied.

ClientQoSAccess

ControlUp

Selectthenameoftheaccesslistappliedtotr

afficintheinbound(up)direction.

OnlyexistingIPaccesslistsarelistedinthemenuandareprefixedwiththeaccesslist

type.TocreateanIPaccesslist,usethepagesintheLAN>AccessControlListsfolder.

•OntheIPACLConfigurationpage,createanewstan

dard,extended,ornamedIP

ACL.

•OntheIPACLRuleConfigurationpage,createoneormorerulestodefinethe

packetmatchcriteriaandthedenyorpermitactionforeachrule.

WhenapacketisreceivedbytheAP,theACLrulesarecheckedforamatch.The

packetispr

ocessedifitispermitted,anddiscardedifitisdenied.

ClientQoSDiffServ

PolicyDown

SelectthenameoftheDiffServpolicyappliedtotrafficfromtheAPintheoutbound

(down)direction.

OnlyexistingDiffServpoliciesarelistedinthemenu.TocreateaDiffServpolicy,use

thepagesinth

eLAN>QoS>DifferentiatedServicesfolder.

•OntheClassConfigurationpage,createaclassanddefineclasscriteria.

•OnthePolicyConfigurationpage,createapolicyandthenassociateaclasswith

thepolicy.

•OnthePolicyClassDefinitionpage,definepolicystatementstodefinewhat

happenstoapa

cketwhenitmatchestheclasscriteria.

ClientQoSDiffServ

PolicyUp

SelectthenameoftheDiffServpolicyappliedtotrafficsenttotheAPintheinbound

(up)direction.

OnlyexistingDiffServpoliciesarelistedinthemenu.TocreateaDiffServpolicy,use

thepagesintheLAN>QoS>Diff

erentiatedServicesfolder.

•OntheClassConfigurationpage,createaclassanddefineclasscriteria.

•OnthePolicyConfigurationpage,createapolicyandthenassociateaclasswith

thepolicy.

•OnthePolicyClassDefinitionpage,definepolicystatementstodefinewhat

happenstoapacketwhenitma

tchestheclasscriteria.

Table328:WirelessNetworkConfiguration(Cont.)

Field Description
