ConfiguringAdvancedSettings

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page598

D‐LinkUWSUserManual

Tochangethesettingsforaradio,youmustfirstselecttheradioyouwanttoconfigure(1or2).Afteryou

changethesettings,clickSubmittoapplythesettings.Changestothesettingsapplyonlytotheselectedradio.

Table353:RadioSettings

Field Description

1‐802.11a/n

2‐802.11b/g/n

Fromthisfield,youcanselecttheradiothatyouwanttoconfigure.Bydefault,Radio

1operatesinIEEE802.11b/g/nmode,andRadio2operatesinIEEE802.11a/nmode.

Ifyouchangethemode,thelabelsfortheradioschangeaccordingly.Changestothe

settingsapplyonlytotheselect

edradio.

TheDWL‐3600APisasingle‐radioAP.AnysettingsyouconfigureforRadio1

(802.11a/n)arenotappliedtotheDWL‐3600AP.IftheselectedHardwareTypeIDfor

theAPprofileisDWL‐3600AP,theradioselectorsarenotavailable.

State Specifywhetheryouwantthera

dioonoroffbyclickingOnorOff.

Ifyouturnoffaradio,theAPsendsdisassociationframestoallthewirelessclientsit

iscurrentlysupportingsothattheradiocanbegracefullyshutdownandtheclients

canstarttheassociationprocesswithotheravailableAPs.

Mode TheMo

dedefinesthePhysicalLayer(PHY)standardtheradiouses.

Selectoneofthefollowingmodesforeachradiointerface:

• IEEE802.11aisaPHYstandardthatspecifiesoperatinginthe5GHzU‐NIIband

usingorthogonalfrequencydivisionmultiplexing(OFDM).Itsupportsdatarates

rangingfrom6to54Mbps.

•IEE

E802.11b/goperatesinthe2.4GHzISMband.IEEE802.11bisan

enhancementoftheinitial802.11PHYtoinclude5.5Mbpsand11Mbpsdata

rates.Itusesdirectsequencespreadspectrum(DSSS)orfrequencyhopping

spreadspectrum(FHSS)aswellascomplementarycodekeying(CCK)topr

ovide

thehigherdatarates.Itsupportsdataratesrangingfrom1to11Mbps.IEEE

802.11gisahigherspeedextension(upto54Mbps)tothe802.11bPHY.Ituses

orthogonalfrequencydivisionmultiplexing(OFDM).Itsupportsdatarates

rangingfrom1to54Mbps.

• IEEE802.11a/noperatesinthe5GHzIS

Mbandandincludessupportforboth

802.11aand802.11ndevices.IEEE802.11nisanextensionofthe802.11standard

thatincludesmultiple‐inputmultiple‐output(MIMO)technology.IEEE802.11n

supportsdatarangesofupto248Mbpsandnearlytwicetheindoorrangeof

802.11b,80

2.11g,and802.11a.

• IEEE802.11b/g/noperate sinthe2.4GHzISMbandandincludessupportfor

802.11b,802.11g,and802.11ndevices.

• 5GHzIEEE802.11nistherecommendedmodefornetworkswith802.11n

devicesthatoperateinthe5GHzfrequencythatdonotneedtosupport802.11a

or802.11b/gdevice

s.IEEE802.11ncanachieveahigherthroughputwhenitdoes

notneedtobecompatiblewithlegacydevices(802.11b/gor802.11a).

• 2.4GHzIEEE802.11nistherecommendedmodefornetworkswith802.11n

devicesthatoperateinthe2.4GHzfrequencythatdonotneedtosupport

802.11aor802.

11b/gdevices.IEEE802.11ncanachieveahigherthroughput

whenitdoesnotneedtobecompatiblewithlegacydevices(802.11b/gor

802.11a).
