ConfiguringtheWirelessDistributionSystem

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page630

D‐LinkUWSUserManual

WhenyouaddanewWDS‐ManagedAPgrouporclickthegroupname,thepagerefreshesandfieldsto

configurethegroupsetting appear.

Figure404:EditWDSManagedAPGroupSettings

ThefollowingtableshowsthefieldsavailabletoconfigureaWDSmanagedAPgroup.

CommandButtons

Thepageincludesthef

ollowingbuttons:

• Submit—Updatestheswitchwiththevaluesyouenter.

Note:AfteryouchangeWDS‐ManagedAPgroupsettings,makesureyoupushtheconfigurationto

otherswitchesinthecluster.

Table367:EditWDSManagedAPGroupSettings

Field Description

WDSGroupName AdescriptivenameoftheWDSAPgroup.Fromthisfield,youcanmodifythenameof

anexistinggroup,ifdesired.

SpanningTree Specifieswhethertoenablespanningtree onallAPsinthisWDSAPgroup.

Spanningtreemustbeenabledifthereareanypotentialloopsinthenetwork.Fo

r

exampleifasatelliteAPhaslinkstotworootAPsthenspanningtreemustbeenabled.

Note:ThespanningtreeprotocolrunningontheAPsinteractswiththespanningtree

protocolrunningontheedgeswitchestowhichtheAPsareconnected.

WDSGroup

Password

Passwordusedfo

rsecuringtheWPA2‐PersonalsecurityontheWDSLink.Range:8–63

ASCIIcharacters.Tocreateorchangethepassword,selecttheEditcheckboxandtypea

passwordintheavailablefield.

ThispasswordmustmatchthepasswordssetonthesatelliteAPsinthisgroup.By

default,thepas

swordisAP‐Group‐n,wherenistheAPgroupID.
