ConfiguringtheWirelessDistributionSystem

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page632

D‐LinkUWSUserManual

WhenyouclickAddfromtheWDSManagedAPSummarypage,thepagerefreshesanddisplaysfieldsto

configuretheWDSManagedAPsettings.

Figure406:WDSManagedAPSettings

ThefollowingtableshowsthefieldsavailabletoconfiguretheWDSManagedAPsettings.

CommandButtons

Thepageincludesthefollowingbuttons:

• Submit—Updateth

eswitchwiththevaluesyouenter.

Note:IfnoAPshavebeenaddedtotheselectedWDSgroup,onlytheAddandRefreshbuttons

display.

Note:AfteryouchangeWDS‐ManagedAPgroupsettings,makesureyoupushtheconfigurationto

otherswitchesinthecluster.

Table369:WDSManagedAPGroupConfiguration

Field Description

APMACAddress MACAddressoftheAP.

STPPriority SpanningTreePriorityforthisAP.TheSTPpriorityisusedonlywhenspanningtree

modeisenabled.

TheSTPprioritydetermineswhichAPisselectedastherootofthespanningtree

andwhichAPhaspreferenceoveranotherAPwhenmultiplee

qualcostpathsexist

inthetopology.ThelowervalueforthespanningtreeprioritymeansthattheAPis

morelikelytobeusedforbridgingdataintothecampusnetwork.Youshould assign

alowerprioritytotheAPsconnectedtothewirednetworkthantothesatelliteAP

TheSTPpriorityvalueisroundeddowntoamultipleof4096.Therangeis0–61440,

andthedefaultvalueis36864.
