VisualizingtheWirelessNetwork

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page653

D‐LinkUWSUserManual

5. Entertherepresentedlengthforoneofthegraphdimensions(heightorwidth).

UsetheSelectionandMeasurementdrop‐downmenustospecifywhetherthelengthistheheightor

width,andwhetheritisinmetersorfeet.Youmustusethesameunitofmeasurementforallfloorswithin

thebuildi

ng.

Thelengthyouenterdeterminesthescaleofthebackgroundimageinrelationtothenetwork

components.ThescaleofthebackgroundimageaffectsthewaytheWLANVisualizationtoolpresentsthe

radiofrequency(RF)coverageoftheaccesspoints,soitisimportanttobeasaccurateaspossiblewhen

youspecifythelength.

6. Cl

ickSave.

TheWLANVisualizationwindowrefreshesanddisplaysthebackgroundimageandayellowruleralongthe

topandleftside.Therulerinformationisbasedontheheightandwidthsettingsspecifiedwhendefining

thegraph.

Whenyoumoveyourmouseoverthegrap

h,thecursorlocationisshowninthebottom‐leftsideofthe

window.
