VisualizingtheWirelessNetwork

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page658

D‐LinkUWSUserManual

View

UngraphedComponents Allowsyoutochangetheviewoftheungraphedcomponentsinthepanel

ontheleft:

•TabView:OrganizesthecomponentwindowsandtheDeviceLocation

windowbytabs.Onewindowdisplaysatatime.

• ListView:OrganizesallcomponentwindowsandtheDeviceLocation

windowverticallyintheleftpa

nel.Thisisthedefaultview.

APPowerDisplay SelectthepowerrangeimagetodisplayforamanagedAP:

• DisablePowerDisplay:Thepowerrangeimageisnotdisplayed

•5GHzBand:ShowsthetransmitpowerforallmanagedAPsthathavea

radiooperatingin802.11aor5‐GHz802.11nmode.

•2.4GHzBa

nd:ShowsthetransmitpowerforallmanagedAPsthathave

aradiooperatingin802.11b/gor2.4GHZ802.11nmode.

Thesizeofthepowerrangeimageisbasedonthetransmitpowerforthe

radio,whichcanbelow,medium,orhigh.Thesizeofthepowerra

nge

imagealsodependsontheactualscalefactorofthecurrentbackground

image.

IftheAPhastworadiosthatareconfiguredinthesamemode,twopower

rangeimagesaredisplayed.

Note:Thecolorofthepowerrangeimageisbasedontheassignedchannel

oftheassociatedra

dio.

IftwoAPsusethesamechannel(orchannelsthatar eclosetogether)and

arewithineachother’stransmissionrange,theAPswillinterferewitheach

otherandwirelessclientswillexperiencepoorWLANperformance.To

reduceinterference,youcantakeoneofthefollowingsteps:

•ReducethetransmitpowerontheAP

• PhysicallyplacetheAPsfurtherapart.

•UsetheautomaticchanneladjustmentalgorithmontheAPsor

staticallysetthechannelssotheyarenon‐interferingchannels.

CAUTION:Powerrangesareforillustrativepurposesonly.Theactualpower

distributionvariesbasedonfactorssuchasofficewallpropagationand

backgroundRFnoise.

tions

ShowManagedAPs ControlswhethertodisplayAPonthegraph.Clearingthecheckboxhides

butdoesnotun‐graphtheobjects.

ShowRFScanAPs ControlswhethertodisplaytheAPsdetectedthroughtheRFscan.Clearing

thecheckboxhidesbutdoesnotun‐graphtheobjects.

ShowManagedAPCl

ients ControlswhethertodisplaywirelessclientsassociatedwithmanagedAPs.

Clearingthecheckboxhidesbutdoesnotun‐graphtheobjects.

ShowDetectedClients Controlswhethertodisplaywirelessclientsthathavebeendetectedbythe

wirelesssystem.Clearingthecheckboxhidesbutdoesnotun‐graphthe

objects.

ShowLoc

ationResults Displaythepointorcirclesolutiononthegraph.Thepointandcircle

solutionsshowtheprobablelocationofadeviceasaresultofasearch.

Table383:WLANVisualizationMenuBarOptions(Cont.)

MenuItem Description
