ConfiguringMultipleSpanningTreeProtocol

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page667

D‐LinkUWSUserManual

8. UsesimilarprocedurestoenableSTPonport0/2.

9. Forceport0/2tobetherootportforMST20,whichisthenon‐rootbridge.

a. GototheLAN>L2Features>SpanningTree>MSTPortConfiguration/Statuspage.

b. FromtheMSTIDmenu,select20.

c. FromtheSlot/Portmenu,se

lect0/2.

d. InthePortPriorityfield,enter64.

e. ClickSubmit.
