MACAccessControlLists

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page362

D‐LinkUWSUserManual

Figure248showsthefieldsavailablewhenyoucreatearuleforaMACACL.

Figure248:MACACLRuleConfiguration(PermitAction)

Table214showsallpossiblefieldsontheMACACLRuleConfigurationpage.Theactualfieldsavailableonthe

pagedependonwhetheryoucreateanewruleormod

ifyanexistingrule,andwhethertheruleactionisPermit

orDeny.

Table214:MACACLRuleConfigurationFields

Field Description

MACACL SpecifiesanexistingMACACL.TosetupanewMACACLusethe“MACAccess

ControlLists”page.

Rule SelectanexistingRuleIDtomodifyorselectCreateRuletoconfigureanew

ACLRule.Enterawholenumberintherangeof1to12thatwillbeuse

dto

identifytherule.Newrulescannotbecreatedifthemaximumnumberofrules

hasbeenreached.Foreachrule,apacketmustmatchallthespecifiedcriteria

inordertobetrueagainstthatruleandforthespecifiedruleaction(Permit/

Deny)totakeplace.

RuleID Thisfieldisonlya

vailableifyouselectCreateRulefromtheRulefield.Entera

newRuleID.AfteryouclickSubmit,thenewIDiscreatedandyoucan

configuretherulesettings.Youcancreateupto12rulesforeachACL.

Action Specifywhatactionshouldbeta

kenifapacketmatchestherule'scriteria:

• Permit:ForwardspacketsthatmeettheACLcriteria.

• Deny:DropspacketsthatmeettheACLcriteria.
