MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page481

D‐LinkUWSUserManual

Figure319:RFScan

ToviewadditionalinformationaboutadetectedAP,clicktheMACaddressoftheAP.

Table286describesthefieldsontheRogue/RFScanpage.

Table286:AccessPointRFScanStatus

Field Description

MACAddress TheEthernetMACaddressofthedetecte dAP.Thiscouldbeaphysicalradiointerfaceor

VAPMAC.ForD‐LinkAPsthisisalwaysaVAPMACaddress.

SSID ServiceSetIDofthenetwork,whichisbroadcastinthedetectedbeaconframe.

PhysicalMode Indicatesthe802.11modebeinguse

dontheAP.

Channel TransmitchanneloftheAP.

Status IndicatesthemanagedstatusoftheAP,whetherthisisavalidAPknowntotheswitchor

aRogueonthenetwork.Thevalidvaluesare:

• Managed:TheneighborAPismanagedbythewirelesssystem.

• Standalone:TheAPismanagedins

tandalonemodeandconfiguredasavalidAPentry

(localorRADIUS).

• Rogue:TheAPisclassifiedasathreatbyoneofthethreatdetectionalgorithms.

•Unknown:TheAPisdetectedinthenetworkbutisnotclassifiedasathreatbythe

threatdetectionalgorithms.

TransmitRate Indicatesthera

teatwhichtheAPiscurrentlytransmittingdata.

Age TimesincethisAPwaslastdet ect edinanRFscan.

StatusentriesfortheRFScanStatuspagearecollectedatapointintimeandeventually

ageout.Theagevalueforeachentryshowshowlongagotheswitchre

cordedtheentry.

YoucanconfiguretheageouttimeforstatusentriesontheWLAN>Advanced

Configuration>Globalpage.Youcanalsomanuallydeletestatusentries.
