MonitoringStatusandStatistics

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page483

D‐LinkUWSUserManual

Table287showstheinformationtheAccessPointRFScanStatuspageshowsforanindividualaccesspoint.

Table287:DetailedAccessPointRFScanStatus

Field Description

MACAddress TheEthernetMACaddressofthedetectedAP.Thiscouldbeaphysicalradiointerface

orVAPMAC.ForD‐LinkAPsthisisalwaysaVAPMACaddress.

SSID ServiceSetIDofthenetwork,whichisbroadcastinthedetectedbeaconframe.

Channel TransmitchanneloftheAP.

Status Indicatesthemanag

edstatusoftheAP,whetherthisisavalidAPknowntotheswitch

oraRogueonthenetwork.Thevalidvaluesare:

•Managed:TheneighborAPismanagedbythewirelesssystem.

• Standalone:TheAPismanagedinstandalonemodeandconfiguredasavalidAP

entry(localorRAD

IUS).

• Rogue:TheAPisclassifiedasathreatbyoneofthethreatdetectionalgorithms.

• Unknown:TheAPisdetectedinthenetworkbutisnotclassifiedasathreatby

thethreatdetectionalgorithms.

InitialStatus IftheAPisnotrogue,theinitialstatusisequaltoStatus(Manag

ed,Standalone,or

Unknown).ForrogueAPs,theinitialstatusistheclassificationpriortothisAP

becomingrogue.

TransmitRate IndicatestherateatwhichtheAPiscurrentlytransmittingdata.

WIDSRogueAP

Mitigation

StatusindicatingwhetherrogueAPmitigationisinprogressforthisAP.Ifmitigation

isnotinpr

ogressthenthisfielddisplaysthereason,whichcanbeoneofthe

following:

•NotRequired(APsnotrogue)

•AlreadymitigatingtoomanyAPs.

•APIsoperatingonanillegalchannel.

•APisspoofingvalidmanagedAPMACaddress.

•APisAdhoc.

Age TimesincethisAPwaslastdet ect edinanRFsc

an.

DiscoveredAge TimesincethisAPwasfirstdetectedinanRFscan.

BSSID BasicServiceSetIdentifieradvertisedbytheAPinthebeaconframes.

PhysicalMode Indicatesthe802.11modebeingusedontheAP.

SecurityMode SecuritymodeusedbytheAP.

802.11nMode IndicateswhetherthisAPsupportsIEEE80

2.11nmode.

BeaconInterval BeaconintervalfortheneighborAPnetwork.

HighestSupportedRate HighestsupportedrateadvertisedbythisAPinthebeaconframes.Therateis

representedinincrementsof1Mbps.

PeerManagedAP IndicateswhetherthisAPismanagedbyaswitchinthecluster.

AdhocNetwork Indicateswhetherthebe

aconframewasreceivedfromanadhocnetwork.

OUIDescription IdentifiesthemanufactureroftheAPorwirelessclientadapterbasedonthe

informationintheOUIdatabaseontheswitch.
