ConfiguringAdvancedSettings

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page602

D‐LinkUWSUserManual

FragThreshold Thefragmentationthresholdlimitsthesizeofpacketstransmittedoverthenetwork.

Acceptablevaluesareevennumbersfrom256‐2345.Packetsthatareunderthe

configuredsizearenotfragmented.Avalueof2346meansthatpacketsarenot

fragmented.

ShortRetries Thevalueinthisfieldindicatesthemaximumnumberoftr

ansmissionattemptson

framesizeslessthanorequaltotheRTSThreshold.Therangeis1‐255.

LongRetries Thevalueinthisfieldindicatesthemaximumnumberoftransmissionattemptson

framesizesgreaterthantheRTSThreshold.Therangeis1‐255.

TransmitLifetime Showsthenumberofmi

llisecondstowaitbeforeterminatingattemptstotransmit

theMSDUaftertheinitialtransmission.

ReceiveLifetime Showsthenumberofmillisecondstowaitbeforeterminatingattemptsto

reassembletheMMPDUorMSDUaftertheinitialreceptionofafragmentedMMPDU

orMSDU.

StationIsolation Whenthisoptionis selected,theAPblockscommunicationbetw

eenwirelessclients.

Itstillallowsdatatrafficbetweenitswirelessclientsandwireddevicesonthe

network,butnotamongwirelessclients.Thisfeatureisdisabledbydefault.

•ToenableMulticastandBroadcastRateLimiting,clickEnabled.

•TodisableMulticastandBroadcastRateDisabled,clickDisabled.

PrimaryChannel Thissettingise

ditableonlywhenachannelisselectedandthechannelbandwidthis

setto40MHz.A40‐MHzchannelcanbeconsideredtoconsistoftwo20‐MHz

channelsthatarecontiguousinthefrequencydomain.Thesetwo20‐MHzchannels

areoftenref erredtoasthePrimaryandSecondarychannels.Th

ePrimaryChannelis 

usedfor802.11nclientsthatsupportonlya20‐MHzchannelbandwidthandfor

legacyclients.

UsethissettingtosetthePrimaryChannelastheupperorlower20‐MHzchannelin

the40‐MHzband.

ShortGuardInterval Theguardintervalisthedeadtime,innanosec

onds,betweenOFDMsymbols.The

guardintervalpreventsInter‐SymbolandInter‐CarrierInterference(ISI,ICI).The

802.11nmodeallowsforareductioninthisguardintervalfromtheaandgdefinition

of800nanosecondsto400nanoseconds.Reducingtheguardintervalcanyielda10%

improvementinda

tathroughput.

Selectoneofthefollowingoptions:

• Enable—TheAPtransmitsdatausinga400nsguardIntervalwhen

communicatingwithclientsthatalsosupportthe400nsguardinterval.

• Disable—TheAPtransmitsdatausingan800nsguardinterval.

RadioResource

Management

RadioResourceMeasurement(RRM)modere

quirestheWirelessSystemtosend

additionalinformationinbeacons,proberesponses,andassociationresponses.

EnableordisablethesupportforradioresourcemeasurementfeatureintheAP

profile.Thefeatureissetindependentlyforeachradioandisenabledbydefault.

MulticastTxRate

(Mbps)

Selectthe802.11rateatwhichthera

diotransmitsmulticastframes.Therateisin

Mbps.Thelowestrateinthe5GHzbandis6Mbps.

SupportedChannels Thisfielddisplaysthechannelsthataresupportedfortheradiomodecurrently

selectedonthepageandforthecountryconfiguredontheGlobalWirelessSettings

page.

AutoEligible SelecttheAut

oEligi bleoptionbeneatheachchanneltoincludethechannelinthe

automaticchannelassignmentprocess.

Table353:RadioSettings(Cont.)

Field Description
