ConfiguringAdvancedSettings

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page603

D‐LinkUWSUserManual

CommandButtons

Thepageincludesthefollowingbuttons:

• Refresh—Updatesthepagewiththelatestinformation.

• Clear—Resetsthesettingsonthepagetothedefaultvalues.

• Submit—Updatestheswitchwiththevaluesyouenter.Toretainthenewvaluesacrossapowercycle,you

mustperformasave(Tool>SaveChang

es).

AvailableMCSIndices ThisfieldshowstheModulationandCodingScheme(MCS)indexvaluessupported

bytheradio.Eachindexcanbeenabledanddisabledindependently.

RateSets Selectthetransmissionratesetsyouwanttheaccesspointtosupportandthebasic

ratesetsyouwanttheaccesspointtoadvertise.

tesareexpressedinmegabitspersecond.

Basic ThesenumbersindicatethedataratesthatallstationsassociatingwiththeAPmust

support.

Supported Thesenumbersindicateratesthattheaccesspointsupports.Youcanselectmultiple

rates.TheAPautomaticallychoosesthemostefficientratebasedonfactorslikeerror

ratesanddi

stanceofclientstationsfromtheAP.

Table353:RadioSettings(Cont.)

Field Description
