ConfiguringtheWirelessDistributionSystem

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page627

D‐LinkUWSUserManual

SupportfortheWDS‐managedAPfeaturewithintheUnifiedWiredandWirelessAccessSystemincludesthe

following:

•ThewirelesssystemcancontainuptotwoWDS‐managedAPgroups.

•EachWDS‐managedAPgroupcancontainuptofourAPs.

•AnAPcanbeamemberofonlyoneWDSAPgroup.

•E

achsatelliteAPcanhaveonlyoneWDSlinkonthesatelliteAPs.ThismeansthatasatelliteAPmustbe

connectedtoarootAP.AsatelliteAPcannotbeconnectedtoanothersatelliteAP.

ThefollowingimageshowsaWDSgroupwithonerootAPandtwosatelliteAPs.Da

shedlinesrepresent

wirelessconnections.

Figure402:WDS‐ManagedAPGroup

TheWDSgroupinFigure402hasthefollowingcharacteristics:

•AllthreeAPsaremanagedbytheUnifiedWiredandWirelessAccessSystem.

•ThegrouphastwoWDSAPlinks:onelinkisbetweentheRootAPandSatelliteAP1,andon

elinkis

betweentheRootAPandSatelliteAP2.

•TheEthernetportonSatelliteAP2isenabledtoallowwiredLANaccesstoremoteofficePCs.

Bydefault,anAPisconfiguredasarootAP.ForanAPtobeattachedtotheWirelessSystemasasatelliteAP,

configurethef

ollowingsettingsontheAPwhileitisinstand‐alonemode:

• SatelliteAPmode.ThissettingenablesthesatelliteAPtodiscoverandestablishWDSlinkwiththerootAP.

Bydefault,theWDSManagedModeisRootAP.

• PasswordforWPA2PersonalauthenticationusedtoestablishtheWDSlink

s.OnlythesatelliteAPsneed

thisconfiguration.TherootAPsgetthepasswor dfromtheswitchwhentheybecomemanaged.

•StaticChannel.TheAPsoneachendofaWDSlinkmustusethesameradioandchanneltocommunicate.

ConfigurethesatelliteAPtouseastaticchannel.Fo

rarootAP,setthestaticchannelwhenyouaddtheAP

totheValidAPdatabaseontheswitch.

• Optionally,toallowtheEthernetportonasatelliteAPtoprovidewiredaccesstotheLAN,youmustset

theWDSManagedEthernetPorttoEnabled.Itisdisabledbyde

fault.

UWS

RootAPS

SatelliteAP1

SatelliteAP2
