ConfiguringVLANs

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page663

D‐LinkUWSUserManual

Figure433:VLANExampleNetworkDiagram

1. AccesstheLAN>L2Features>VLAN>VLANConfigurationpage.

2. SelecttheCreateoptionintheVLANfield.

3. SelecttheVLANID‐Rangeoptionandenter2to3intherangefields.

4. ClickSubmit.

5. SelectVLAN2fromtheVLANIDandNameLis

6. SelecttheParticipateoptionintheVLANfield.

7. Forports0/1and0/2,selectIncludefromtheParticipationmenutospecifythattheseportsaremembers

ofVLAN2.

8. FromtheTaggingmenu,selectTaggedinthefirstrow(All)tospecifythatframeswillalwaysbetransmitted

Port 0/1

VLAN 2

Port 0/2

VLANs 2 & 3

Port 0/3

VLAN 3

Port 0/4

VLAN 3

Layer 3 Switch

VLAN 2

VLAN 3
