ConfiguringIPAccessControlLists

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page354

D‐LinkUWSUserManual

Figure242showsthefieldsavailablewhenyoucreatearuleforanextendedIPACL.

Figure242:IPACLRuleConfiguration(ExtendedACLRule)

Table212showsallpossiblefieldsontheIPACLRuleConfigurationpage.Theactualfieldsavailableonthe

pagedependonwhattypeofruleyouc

onfigure,whetheryoucreateanewruleormodifyanexistingrule,and

whethertheruleactionisPermitorDeny.

Table212:IPACLRuleConfigurationFields

Field Description

IPACL ThemenucontainstheexistingIPACLsconfiguredonthepage.Tosetupanew

IPACL,see“ConfiguringIPAccessControlLists”onpage351.

Rule SelectanexistingRuleIDtomodifyorselectCre a teRuletoconfigureanew

ACLRule.Newrulescannotbecreatedifthema

ximumnumberofruleshas

beenreached.Foreachrule,apacketmustmatchallthespecifiedcriteriain

ordertobetrueagainstthatruleandforthespecifiedruleaction(Permit/

Deny)totakeplace.

RuleID ThisfieldisonlyavailableifyouselectCreateRulefromtheRulefield.Ent

era

newRuleIDwhichisawholenumberintherangeof1to12thatwillbeused

toidentifytherule.AfteryouclickSubmit,thenewIDiscreatedandyoucan

configuretherulesettings.Thenumberofrulesyoucancr

eateinanACLis

platformdependent.

Action SelectstheACLforwardingaction.ClickConfiguretochangetheaction.Select

thedesiredactionfromthedropdownmenu,andthenclickSubmitorCancel

toreturntotheRuleConfigurationpage.Possiblevaluesare;

• Permit.ForwardspacketswhichmeettheACLcriteria.

• Den

y.DropspacketswhichmeettheACLcriteria.
