ConfiguringIPAccessControlLists

D-Link UnifiedWiredandWirelessAccessSystem

November2011 Page355

D‐LinkUWSUserManual

Logging ThisfieldisonlyvisibleforaDenyAction.WhensettoTrue,loggingisenabled

forthisACLrule(subjecttoresourceavailabilityinthedevice).IftheAccess

ListTrapFlagisalsoenabled,thiswillcauseperiodictrapstobegenerated

indicatingthenumberoftimesthisrulewen

tintoeffectduringthecurrent

reportinterval.Afixed5minutereportintervalisusedfortheentiresystem.

AtrapisnotissuediftheACLrulehitcountiszeroforthecurrentinterval.

TimeRangeName UsethisfieldtoimposeatimelimitationontheACLrule.Whenyo

uclick

Configure,youcanselectaconfiguredtimerangeorcreateanewnamedtime

range.Toconfigurethetimerangevalues,usetheLAN>Administration>

TimeRanges>TimeRangeEntryConfigurationpage.

IfatimerangewiththespecifiednamedoesnotexistandtheACLc

ontaining

thisACLruleisappliedtoaninterfaceorboundtoaVLAN,thentheACLrule

isappliedimmediately.IfatimerangewithspecifiednameexistsandtheACL

containingthisACLruleisappliedtoaninterfaceorboundtoaVLAN,thenthe

ACLruleisappl

iedwhenthetime‐rangewithspecifiednamebecomesactive.

TheACLruleisremovedwhenthetime‐rangewithspecifiednamebecomes

inactive.

AssignQueueID ThisfieldisonlyvisiblewhentheActionisPermit.Usethisfieldtospecifythe

hardwareegressqueueidentifierusedtohand

leallpacketsmatchingthisAP

ACLRule.ClickConfigure,andthenenteranidentifyingqueuenumber(0to

7)intheappropriatefield.ClickSubmitorCanceltoreturntotheRule

Configurationpage.

MirrorInterface ThisfieldisonlyvisiblewhentheActionisPermit.Usethisfieldtospe

cifythe

specificegressinterfacewherethematchingtrafficstreamiscopiedin

additiontobeingforwardednormallybythedevice.ClickConfigure,andthen

selectaninterfacefromthedropdownlist.Packetsthatmeettheruleare

mirroredontheinterfaceyouselect.ClickSubmitorCanceltore

turntothe

RuleConfigurationpage.

MatchEvery RequiresapackettomatchthecriteriaofthisACL.ClickConfigure,andthen

selectTrueorFalsefromthedropdownlist.ThenclickSubmitorCancelto

returntotheRuleConfigurationpage.Truesignifiesthatallpacketswillmatch

theselectedIPAC

LandRuleandwillbeeitherpermittedordenied.Match

Everyisexclusivetotheotherfilteringrules,soifMatchEveryisTrue,the

otherrulesonthescreendonotappear.Toconfigurespecificmatchcriteria

fortherule,removetheruleandre‐createit,orr

econfigure‘MatchEvery’to

‘False’fortheothermatchcriteriatobevisible.

ProtocolKeyword Specifythatapacket’ sIPprotocolisamatchconditionfortheselectedIPACL

rule.ThepossiblevaluesareICMP,IGMP,IP,TCP,andUDP.Eitherthe‘Protocol

Keyword’fieldorthe‘ProtocolNumber’fieldcanbeuse

dtospecifyanIP

protocolvalueasamatchcriteria.ClickConfigure,andthenselectthe

protocolkeywordfromthedropdownlist.ClickSubmitorCanceltoreturnto

theRuleConfigurationpage.

ProtocolNumber Specifythatapacket’ sIPprotocolisamatchconditionfortheselectedIPAC

L

ruleandidentifytheprotocolbynumber.Theprotocolnumberisastandard

valueassignedbyIANAandisinterpretedasaintegerfrom0to255.Eitherthe

‘ProtocolNumber’fieldorthe‘ProtocolKeyword’fieldcanbeusedtospecify

anIPprotocolvalueasama

tchcriteria.

Table212:IPACLRuleConfigurationFields(Cont.)

Field Description
