22
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
57. Hex bolt
58. Spool
59. Spring
60. Line trimmer head
61. Latch opening
Figure 14
62. Lines
63. Lines hole
RBC430SBS
Figure 1
1. Shoulder strap
2. Tri-arc Blade
3. Drive shaft
4. Coupler
5. Strap hanger
6. Ignition switch
7. Trigger lock
8. Left handle
9. Primer bulb
10. Fuel cap
11. Recoil starter
12. Throttle trigger
13. Latch
14. Right handle
15. Wing knob
16. Blade deflector
17. Choke lever
18. Grass deflector
19. Cutting line
20. Reel easy
TM
string head
20b.Pro cut 
TM
string head
Figure 2
21. Lock button
22. Guide recess
23. Power head (upper) shaft
24. Position hole
Figure 3
25. Hole on the attachment hanger to fit lock button of
lower booms
26. Attachment hanger
27. Hole on lower attachment
Figure 4
28. Clamp
29. Screw
30. Mounting bracket
Figure 5
31. Gear case assembly
32. Holding pin tool
33. Mounting bracket
34.Stamping, wrench, combination
35. Retainer
36. Nut
Figure 10
37. Trimmer line cut-off blade
Figure 12
38. Start position
39. Run position
Figure 17
40. Tri-arc Blade protector
Figure 15
41. Idle speed screw
Figure 19
42. Filter screen
43. Air filter cover
Figure 20
44. Oil cap/dipstick
45. Hatched area
46. Oil fill hole
47. Funnel
Figure 13
48. Drive shaft
Figure 18
49. Cover
50. Latches
51. Bump / Feed knob
52. Hex bolt
53. Spool
54. Spring
55. Line Trimmer head
56. Latch opening
Figure 21
57. Top cover
58. Screw
59. Spark plug
Figure 16
60. Line slot
61. Line hole
ASSEMBLY
UNPACKING
This product requires assembly.
Q Carefully remove the tool and any accessories from
