24
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
align the 3 screws on the grass deflector to the screw
holes on the blade guard.
Q Using the combination wrench supplied, tighten all 3
screws securely.
WARNING
Always stop the engine and remove the spark
plug wire before making any adjustments such
as changing cutting heads; this is to reduce the
risk of serious personal injury.
INSTALLING REEL EASY STRING HEAD
See Figure 6.
Q Open the Reel easy line trimmer head by depressing the
latches on each side. The contents of the line trimmer head
are spring loaded, so keep your other hand over the line
trimmer head cover while depressing the latches.
Q Remove the line trimmer head cover, knot and spool then set
aside.
Q Place the line trimmer head on the drive shaft. Make sure the
line trimmer head is fully seated.
Q Install the hex bolt into the opening on the drive shaft and
secure using the hexshaped opening in the knob to tighten.
NOTE: Only use the knob to tighten the bolt. The use of other tools
may allow over tightening of the bolt, which could damage the line
trimmer head.
Q Install the spring into the line trimmer head and push down to
seat.
Q Installing the spool. For the RLT430SES curved line trimmer
attachment, the spool should be placed so "this side out
for curved shaft" is visible. If you are using a straight shaft
attachment with the Real easy cutting head the spool should
be placed "the side out for straight shaft" is visible.
Q Replace the knob in the spool.
Q Replace the line trimmer head cover, aligning latches with
openings in the line trimmer head. Press cover and line
trimmer head together until both latches snap into openings
securely.
Q Install line as described in the next section of this manual.
ATTACHING THE SHOULDER STRAP
Note: Always use the shoulder strap/harness with your
brushcutter.
RBC430SES
Follow these steps to attach the shoulder strap.
Q Connect the latch on the strap to the hanger bracket.
Q Adjust the strap to a comfortable position.
RBC430SBS
See Figure 4.
Follow these steps to attach the shoulder strap.
Q Connect the latch on the shoulder harness to the
strap hanger.
Q Adjust the strap to a comfortable position.
FEATURES
RBC430SES RBC430SBS
Engine Displacement 30 cm³ 30 cm³
Cutting Path Diameter 18 in / 457 mm 18 in / 457 mm
String Diameter 2.4 & 2.7 mm 2.4 & 2.7 mm
Blade Diameter 200 mm 200 mm
Blade type Triarc blade 8"(200mm)
Triarc blade
8"(200mm)
Mass(without fuel with string head) 5.90 kg 6.40 kg
Mass(without fuel, with blade head) 5.85 kg 6.35 kg
Volume (fuel tank) 350 cm³ 350 cm³
Volume (oil tank)
Optimum: 65 cm³
Max: 125 cm³
Optimum: 65 cm³
Max: 125 cm³
Maximum engine perform
(in accordance with ISO8893)
0.70 kW 0.70 kW
Maximum rotational frequency of the spindle 10000/min 10000/min
Engine speed (rotational frequency) at recommended max.
spindle rotational frequency
12000/min 12000/min
