28
English (original instructions)
EN
FR DE ES IT PT NL SV DA NO FI HU CS RU RO PL SL HR ET LT LV SK BG
Q The trimmer cuts when passing the unit from left to
right. This will avoid throwing debris at the operator.
Avoid cutting in the dangerous area shown in
illustration.
Q Use the tip of string to do the cutting; do not force
string head into uncut grass.
Q Wire and picket fences cause extra line wear, even
breakage. Stone and brick walls, curbs, and wood
may wear line rapidly.
Q Avoid trees and shrubs. Tree bark, wood mouldings,
siding, and fence posts can easily be damaged by
the string.
GRASS DEFLECTOR LINE TRIMMING CUT-OFF
BLADE
See Figure 10.
The trimmer is equipped with a line trimming cut-off blade
on the grass deflector. For best cutting, advance line until
it is trimmed to length by the cut-off blade. Advance the
line whenever you hear the engine running faster than
normal, or when trimming efficiency diminishes. This will
maintain best performance and keep the line long.
STARTING AND STOPPING
To start a cold engine:
See Figure 9a.
DO NOT squeeze the throttle trigger until the engine
starts and runs.
Note: If you are having difficulties starting this product,
please refer to the troubleshooting guide in the manual.
When starting the product the first time after the
purchase the starting might be more difficult than for the
following starts.
Q Lay the trimmer on a flat, even surface.
Q Place the engine switch to the “I” position.
Q PRIME - press the primer bulb 10 times slowly.
Q SET the start lever to the “START” position.
Q PULL the starter rope until the engine attempts to
start.
Q SET the start lever back to the RUN position.
Note: If the engine stops, set the start lever to the RUN
position and pull the starter grip until engine starts.
Q Squeeze throttle trigger to run
To start a warm engine:
See Figure 9b.
Make sure there is fuel visible in the primer bulb, if not,
follow cold start procedure.
Q PULL the rope until the engine starts.
To stop the unit:
Place the engine switch to the stop “O” position.
MAINTENANCE
WARNING:
When servicing, use only identical replacement
parts. Use of any other parts may create a
hazard or cause product damage.
WARNING:
Always wear safety goggles or safety glasses
with side shields during tool operation. If
operation is dusty, also wear a dust mask.
WARNING:
Before inspecting, cleaning, or servicing the
machine, shut off engine, wait for all moving
parts to stop, and disconnect spark plug lead
and move it away from spark plug. Failure to
follow these instructions can result in serious
personal injury or property damage.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use.
Use clean cloths to remove dirt, dust, lubricant, grease.
WARNING:
Do not at any time let brake fluids, petrol,
petroleum-based products, penetrating
lubricants, etc., come in contact with plastic
parts. Chemicals can damage, weaken or
destroy plastic which may result in serious
personal injury.
You can often make adjustments and repairs described
here. For other repairs, have the trimmer serviced by an
authorised service dealer.
INSTALLING PRO CUT II LINE HEAD
See Figure 13.
Q Stop the engine and disconnect the spark plug wire.
Q Remove currently installed line head.
Q Install the line head on the drive shaft until fully
seated.
Q Install the spool retainer and turn counter clockwise.
Q Install cutting line as described in the next section of
this manual.
INSTALLING CUTTING LINE IN PRO CUT II LINE
HEAD
See Figure 14 for RBC430SES
See Figure 16 for RBC430SBS
Use monofilament line between 2.4mm and 2.7mm
diameter. Use original manufacturer’s replacement line
