GENERAL CHASSIS
4-6
▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼▼
a. Activate the diagnostic mode and select
the diagnostic code number “34”.
Refer to "FUEL INJECTION SYSTEM" on
page 8-29.
b. Set the engine stop switch to “ ”.
c. Check that the intake funnel operate
smoothly strokes from the upper position to
the lower seating position.
▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲▲
