REAR BRAKE
4-34
Disassembling the rear brake master cylinder
Order Job/Parts to remove Q’ty Remarks
1 Brake master cylinder kit 1
2 Hose joint 1
3Bush 1
4 Brake master cylinder body 1
For assembly, reverse the disassembly pro-
cedure.
