FRONT BRAKE
4-21
Disassembling the front brake master cylinder
Order Job/Parts to remove Q’ty Remarks
1 Brake master cylinder kit 1
2 Bleed screw 1
3 Brake master cylinder body 1
For assembly, reverse the disassembly pro-
cedure.
